Yorkville Synergy Array Series, Professional DJ System, PA Sound System, Recording

Lightyear Music

$16,999.99 $21,000.00

  Lease to own   Pay as low as   $/week

← Previous Product Next Product →
Share:

AMAZING NEW SOUND SYSTEM FROM YORKVILLE!



This System Includes:

  • Yorkville Synergy Array Series
  • Yamaha MG10XU Mixer
  • 2 sets of UHF Dual Wireless Mics (4 Mics Total)
  • 4 Boom Microphone Stands
  • All Cables
The video below has the Yamaha mixer as a reference. Included with this system is the Soundcraft mixer.


    Yamaha MG10XU Mixer Features:

    • Yamaha MG10XU 10-Channel Compact Stereo Mixer and USB Audio Interface
      The MG10XU offers 4 XLR channels with 3 band EQ, two of which feature 1-Knob Compression, as well as 4 mono and 3 stereo line inputs. In addition to balanced main and headphone outputs, MG10 also features Monitor and Aux(FX) Send outputs for added flexibility. Add to all of this a 24-bit USB Audio Interface and the powerful SPX Digital Multi Effect Processor, and the MG10XU is a perfect mixer for practice spaces, acoustic venues, and of coarse the electronic musician or keyboard player who deserves total control to mix their many components.

    Dual UHF Microphones

    UHF
    Specs:
    Frequency Range 590-890Mhz
    100 Frequencies
    30Mhz Bandwidth
    12v Power Supply
    Each Microphone runs on 2 AA batteries
    Super Strong Signal

    Yorkville Synergy Array Series

    The Synergy Array Series is a truly revolutionary active point source system with unmatched flexibility, power, and directivity control. The Synergy System offers users unrivaled simplicity without sacrificing sonic performance.

    Subwoofer Specifications

    Active or Passive Active
    Program Power (Watts) 6500 Watts Program (13000 Watts Peak)
    Measured Max SPL (C-Weighted, Max Hold) 130 dB Cont. 136 dB Peak
    Frequency Response (Hz +/- 3dB) 31Hz-100Hz
    Crossover Frequency (Hz) 100 Hz lowpass
    Cabinet Configuration Bass Reflex
    Driver Configuration 3x15" LF woofer
    LF Driver(s) 15" Ceramic with 3" Voice Coil
    LF Program Power(Watts) 6500 Watts Program (13000 Watts Peak)
    LF Impedance (Ohms) 2.7 ohm Load (3x 8 ohm)
    LF Protection Excursion, Voice Coil Thermal (RMS)
    LF Power Amplifier (Watts) 6500 Watts Program (13000 Watts Peak)
    LF Amplifier Type Class D
    Cooling Scheme Convection
    Power Cable Removable Locking Powercon True Input and Loop Thru Output
    Power Switch Yes
    Power Consumption (typ/max) 600 VA / 1200 VA
    Inputs 1 XLR with 2x XLR Parallel out, Impedance 35k ohms
    Input Sensitivity (Vrms Sine) Line in 1.4 at center, 0.56 at max
    Level Controls Volume, -∞,0dB,8dB (Min, Top, Max)
    EQ Controls Thermal Limiter Advance for power consumption management
    Limiter Excursion, Thermal (RMS), Clipping
    LED Indicators Power, Excursion Limit, Thermal (RMS) Limit, Input Clip, Activity
    Enclosure Materials Multiply 15mm Birch Plywood
    Standard Rigging Hardware RAIL and LOCKBAR Rigging System (Top and Bottom)
    Stacking Feature Interlocking UHMW Feet (Top and Bottom)
    Covering / Finish Paint
    Dimensions (DWH xbackW, inches) 24 x 21 x 51.5 x 12.25
    Dimensions (DWH xbackW, cm) 60.9 x 53.3 x 130.8 x 31.1
    Weight (lbs/kg) 236/107

    Speaker Specifications

    Active or Passive Active
    Program Power (Watts) 2600 Watts Program (5000 Watts Peak)
    Biampable Triamp
    Measured Max SPL (C-Weighted, Max Hold) 131 dB Cont. 137 dB Peak
    Frequency Response (Hz +/- 3dB) 55Hz-18k
    Dispersion (°H x °V) 22.5x45 Asymetrical 10 Up, 35 Down
    Crossover Frequency (Hz) 400Hz, 7kHz
    Cabinet Configuration Patented Synergy Horn and Paraline Lens Technology
    Driver Configuration 1x15" LF woofer, 1x MF/HF Co-ax Compression
    HF Driver(s) 1.75" Diaphragm/Voice Coil Annular Co-axial
    HF Program Power (Watts) 300 Watts
    HF Impedance (Ohms) 16 ohm Load
    HF Protection Peak and Average Limiting
    MF Driver(s) 3.5" Diaphragm/Voice Coil Annular Co-axial
    MF Program Power (Watts) 300 Watts
    MF Impedance (Ohms) 16 ohm Load
    MF Protection Peak and Average Limiting
    LF Driver(s) 1x15" Neo Woofer with 3.5" Voice Coil
    LF Program Power(Watts) 2000 watts Program (4000 watts Peak)
    LF Impedance (Ohms) 8 ohm Load
    LF Protection Excursion, RMS
    HF Power Amplifier (Watts) 300W
    HF Amplifier Type 3-Tier Class H
    MF Power Amplifier (Watts) 300W
    MF Amplifier Type 3-Tier Cllass H
    LF Power Amplifier (Watts) 2000W
    LF Amplifier Type Class D
    Cooling Scheme Convection
    Power Cable Removable Locking Powercon True Input and Loop Thru Output
    Power Switch Yes
    Power Consumption (typ/max) 220 VA / 400 VA
    Inputs 1 XLR, 2 x XLR Loop
    Input Sensitivity (Vrms Sine) Line in 1.4 at center, 0.56 at max
    Level Controls Volume
    EQ Controls HF/MF Boost select,
    Fullrange/Sub switch
    LED Indicators Power, Limit, Clip
    Enclosure Materials Multiply 15mm Birch Plywood
    Standard Rigging Hardware RAIL and LOCKBAR Rigging System (Top and Bottom)
    Stacking Feature Interlocking UHMW Feet (Top and Bottom)
    Covering / Finish Paint
    Dimensions (DWH xbackW, inches) 24 x 21 x 26.5 x 12.25
    Dimensions (DWH xbackW, cm) 60.9 x 53.3 x 67.3 x 31.1
    Weight (lbs/kg)

    115/52.1
